Protection System Audits and Protection relay Setting Studies

Protection System Audits
Protection is heart of Power System. Protection System Audits help ensure an efficient and effective power system protection system, limiting outage and related damage also ensuring a fast restoration of service.

Through our experienced engineers, Power Engineering and Automation carry out Protection System Audits both an industry and utilities.

Protection System Audits include:

  • Collation of all drawings and documentation
  • Site survey of all protection gear
  • Fault level calculations
  • Assessment of protection quality and co-ordination
  • Updating drawings, setting schedules and relay coordinating schemes and curves
  • Recommendation of required changes to ensure adequate protection
  • Preparation of full report, a controlled document with non-disclosure agreement signed off

Protection Setting Studies

These should be carried out on new power systems such as a new industrial installation, but also done for modifications to existing power systems. The full protection study comprises:

  • Establish system data
  • Fault level calculation as necessary
  • Liaison with interested parties like neighboring utilities
  • Produce setting schedule
  • Prepare drawings and co-ordination graphs
  • Preparation of report on settings and recommendations
  • Asset Replacement/Renovation Management
  • Preparation of full report, a controlled document with non-disclosure agreement signed off
